One-stop solution of PCB design and manufacturing




Items

PCB capacity

 Product name

 SMT circuit board manufacturer  electronic assembly pcb

 Material

 FR-4; High TG FR-4; Aluminum; Rogers etc

 PCB type

 Rigid, flexible, rigid-flexible;HDI PCB,High frequency PCB

 Layers

 1 to 20 layers

 Max PCB dimension

 620mm*520mm

Board Thickness

 0.2mm-6mm(±10%)

Min Hole Size

 ≥0.1mm (4 mil)

Copper Thickness

 0.5oz-8oz(18-280um)

Copper Plating hole

 20um-50um

Solder mask

 Green,white,blue,red,yellow,black,sub green, sub black,orange, purple

Silk print

 white,yellow,black

 Min Trace Width

 0.075mm (3mil)

 Min Space Width

 0.1mm (4 mil)

 Surface finish

 LF HASL,HASL, Imm Gold, Imm Silver,  immersion Tin, OSP,ENIG,Gold plated,carbon oil;

impendence board

 FR-4,Rogers,ArlonTaconic

Impedance tolerance

 ±10%

HDI Technology

 Non cross blind burial hole,three times lamination




  1. SMT Service
