Items

PCBA capacity

Product name

 SMT manufacturer  PCB assembly   double-side welding

Assembly details

 3 SMT lines,2 THT soldering lines,BGA

Testing on products

 Testing jig/mold, AOI Test, Functional test

Quantity

 Min quantity: ≥1pcs. Prototype, small order, mass order, all OK

Files needed

 PCB : Gerber files(CAM, PCB, PCBDOC)

 Components: Bill of Materials(BOM list) in excel file

 Assembly:Pick-N-Place file

 Others:Testing documents (if necessary)



 Min size: 0.25*0.25 inches(6*6mm)

PCB Panel Size

 Max size:620*560mm

 Components details

 Passive components

 BGA and VFBGA

 Leadfree Chip Carriers/CSP

 Double-sided SMT Assembly

 Fine BGA Pitch to 0.2mm(8mil)

 BGA Repair and Reball

 Part Removal and Replacement

PCBA package

 Inside:ESD bags+ blister board;Outside:carton

Delivery ways

 By air:DHL,FEDEX,UPS;by sea:forwarder according to buyer’s request
